Schneider Electric GV3ME40
motor circuit breaker GV3-ME - 25..40 A - screw clamp terminal - thermomagnetic
This Schneider Electric GV3ME40 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Motor circuit breakers range and is referenced internally as PartLogic SKU PL26801445884.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range | TeSys |
| Product name | TeSys GV3 |
| Product or component type | Circuit breaker |
| Device short name | thermal magnetic circuit breaker |
| Device application | Motor |
| Poles description | 3P |
| Network type | AC |
| Control type | Push-button |
| Motor power kW | 15 kW at 400...415 V AC 50/60 Hz | 18.5 kW at 400...415 V AC 50/60 Hz | 22 kW at 500 V AC 50/60 Hz | 18.5 kW at 500 V AC 50/60 Hz | 22 kW at 660...690 V AC 50/60 Hz | 30 kW at 660...690 V AC 50/60 Hz |
| Trip unit technology | Thermal-magnetic |
| Utilisation category | Category A conforming to IEC 60947-2 | AC-3 conforming to IEC 60947-4-1 |
| Connections - terminals | Power circuit: screw clamp terminal 1 cable(s) 2.5…35 mm²solid | Power circuit: screw clamp terminal 1 cable(s) 2.5 mm²flexible without cable end | Power circuit: screw clamp terminal 2 cable(s) 16 mm²flexible with cable end |
| Network frequency | 50/60 Hz |
| Mounting mode | Fixed |
| Mounting support | Plate | Rail |
| Mounting position | Vertical | Horizontal |
| Thermal protection adjustment range | 25…40 A conforming to IEC 60947-4-1 |
| Phase failure sensitivity | Yes conforming to IEC 60947-4-1 § 7-2-1-5-2 |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 | 600 V AC 50/60 Hz conforming to UL 508 | 600 V AC 50/60 Hz conforming to CSA C22.2 No 14 |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-2 |
| [Ith] conventional free air thermal current | 40 A conforming to IEC 60947-4-1 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| Power dissipation per pole | 8 W |
| Mechanical durability | 30000 cycles |
| Electrical durability | 30000 cycles for AC-3 at 440 V In/2 |
| Maximum number of switchings | 25 cyc/h |
| Rated duty | Continuous conforming to IEC 60947-4-1 |
| Tightening torque | 5 N.m - on EverLink BTR screw connectors - cable 2.5…16 mm² | 5 N.m - on EverLink BTR screw connectors - cable 2.5…3.5 mm² |
| Breaking capacity | 100 kA Icu at 230...240 V AC 50/60 Hz conforming to IEC 60947-2 | 15 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 | 10 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 | 4 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 | 2 kA Icu at 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ics] rated service short-circuit breaking capacity | 100 % at 230...240 V AC 50/60 Hz conforming to IEC 60947-2 | 50 % at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 | 60 % at 440 V AC 50/60 Hz conforming to IEC 60947-2 | 100 % at 500 V AC 50/60 Hz conforming to IEC 60947-2 | 100 % at 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| Height | 120 mm |
| Width | 61 mm |
| Depth | 113 mm |
| Net weight | 0.7 kg |
| Standards | IEC 60947-2 | IEC 60947-4-1 | BS EN | DIN EN 60947-2 | DIN EN 60947-4-1 | EN 60947-2 | EN 60947-4-1 | NF EN |
| Product certifications | UL | CSA | LROS (Lloyds register of shipping) |
| Protective treatment | TC |
| IP degree of protection | IP20 conforming to IEC 60529 (open mounted) | IP55 conforming to IEC 60529 (in enclosure) |
| Shock resistance | 22 gn 20 ms conforming to IEC 60068-2-27 |
| Vibration resistance | 2.5 gn (f= 0…25 Hz) conforming to IEC 60068-2-6 |
| Ambient air temperature for operation | -20…40 °C in enclosure | -20…60 °C open mounted |
| Ambient air temperature for storage | -40…80 °C |
| Fire resistance | 960 °C conforming to IEC 60695-2-1 |
| Operating altitude | <= 3000 m |
| Resistance to mechanical impact | 0.5 J |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
