Schneider Electric GV2P21
Motor circuit breaker, TeSys GV2, 3P, 17-23 A, thermal magnetic, screw clamp terminals
This Schneider Electric GV2P21 is supplied brand new by PartLogic for switching, motor protection, starting, control panel builds, machinery maintenance and industrial electrical applications. It forms part of our Industrial automation > Motor control > Motor circuit breakers range and is referenced internally as PartLogic SKU PL26902104326.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Current Rating | 23 A |
| Depth | 97 mm |
| Height | 89 mm |
| Length | 97 mm |
| Max Operating Temperature | 60 °C |
| Min Operating Temperature | -20 °C |
| Number of Poles | 3 |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Termination | Screw |
| Voltage Rating | 690 V |
| Voltage Rating (AC) | 690 V |
| Weight | 350 g |
| Width | 45 mm |
