Schneider Electric ATV312HU55N4
The Schneider Electric ATV312HU55N4 is an adjustable speed drive with a power output of 5.5 kW (7.5 hp) for efficient motor control. This device accommodates a wide input voltage range and offers features for robust performance in demanding applications.
This Schneider Electric ATV312HU55N4 is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives range and is referenced internally as PartLogic SKU PL26805461941.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Line | ATV312 |
| Part Number | ATV312HU55N4 |
| EAN | 3606480077678 |
| Weight | 5.00 lbs (2.27 kg) |
| Device Type | Adjustable speed drive |
| Power Capacity | 5.5 kW (7.5 hp) |
| Physical Dimensions (H × W × D) | 232 × 180 × 172 mm |
| Integrated EMC Filter | Yes |
| Enclosure Protection Rating | IP20, IP21, IP31, IP41 (depending on part) |
| Supported Communication Protocols | Modbus, CANopen |
| Braking Torque Performance | 150% with or without braking resistor |
| Input Voltage Range | 380–500 V ±15% |
| Phases | Three-phase |
| Frequency Range Supported | 50–60 Hz ±5% |
| Output Frequency Range | 0–500 Hz |
| Input Current | 21.9 A at 380 V; 16.5 A at 500 V |
| Apparent Power Rating | 15 kVA |
| Overload Handling Capability | 170–200% of nominal torque |
| Motor Control Method | Sensorless flux vector modulation |
| Brand | Schneider Electric |
