Schneider Electric ATV312HU22N4
Schneider Electric's ATV312HU22N4 is a variable frequency drive that controls induction motors. This unit has a motor capacity of 2.2 kW, equivalent to approximately 3 horsepower, and features a robust integrated heat sink for heat dissipation.
This Schneider Electric ATV312HU22N4 is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives range and is referenced internally as PartLogic SKU PL26805594385.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Line | ATV312 |
| Part Number | ATV312HU22N4 |
| EAN | 3606480077616 |
| Weight | 5.00 lbs (2.27 kg) |
| Device Classification | Variable frequency drive |
| Intended Motor Type | Induction motors |
| Mounting Configuration | Integrated heat sink |
| Motor Capacity | 2.2 kW or 3 horsepower |
| Input Voltage Range | 380 to 500 V with -15% to +10% tolerance |
| Input Frequency Range | 50 to 60 Hz with ±5% variation |
| Phase Configuration | Three-phase input |
| Power Rating | 5.9 kVA |
| Peak Current Rating | 8.3 A for 60 seconds |
| Built-in Filter | Electromagnetic compatibility (EMC) filter |
| Nominal Output Current | 5.5 A at 4 kHz switching frequency |
| Output Frequency Range | 0 to 500 Hz |
| Deceleration Braking Capability | Up to 150% torque for 60 seconds with external braking resistor |
| Control Algorithm | Sensorless vector control with pulse-width modulation (PWM) |
| Supported Communication Interfaces | CANopen, Modbus |
| Brand | Schneider Electric |
