Schneider Electric ATV312HD11N4
The Schneider Electric ATV312HD11N4 model is a variable-frequency drive designed for a wide range of applications. It boasts an apparent power rating of 25 kVA and an output frequency adjustable between 0 and 500 Hz. The drive employs sensorless flux vector control for effective motor management.
This Schneider Electric ATV312HD11N4 is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives range and is referenced internally as PartLogic SKU PL26805673562.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Type | Variable frequency drive |
| Product Line | ATV312 |
| Part Number | ATV312HD11N4 |
| EAN | 3606480077715 |
| Weight | 5.00 lbs (2.27 kg) |
| Apparent Power Rating | 25 kVA |
| Continuous Current Output | 27.7 A at a switching frequency of 4 kHz |
| Output Frequency Range | Adjustable from 0 to 500 Hz |
| Motor Control Profile | Sensorless flux vector control using pulse-width modulation |
| Peak Current for Overload | 41.6 A sustained for 60 seconds |
| Built-in EMC Filter | Included |
| Braking Performance | Up to 150% with or without braking resistor for up to 60 seconds |
| Communication Interfaces | Supports Modbus and CANopen protocols |
| Input Current | 37.2 A at 380 V, 28.4 A at 500 V |
| Phase Configuration | Three-phase |
| Frequency of Supply | 50/60 Hz, tolerance ±5% |
| Voltage Input Range | 380 to 500 V, tolerance ±15% to -10% |
| Rated Motor Power | 11 kW |
| Motor Power in Horsepower | 15 hp |
| Brand | Schneider Electric |
