Schneider Electric 33685
Industrial scissors, 215mm length, stainless steel blade.
This Schneider Electric 33685 is supplied brand new by PartLogic for control panels, machine wiring, power distribution, industrial maintenance and replacement applications. It forms part of our Industrial automation > Electrical distribution > Circuit breakers > Accessories range and is referenced internally as PartLogic SKU PL26911613551.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Device short name | MN delay unit |
| Product or component type | Time delay relay |
| Device application | Control |
| Range compatibility | Masterpact MasterPact NT | Masterpact MasterPact NW | ComPact ComPact NS630b...1600 | ComPact ComPact NS1600b...3200 | Masterpact MasterPact NW UL 489 | Masterpact MasterPact NT UL 489 | Masterpact MasterPact NW DC |
| Voltage release type | Undervoltage release |
| [Uc] control circuit voltage | 200...250 V AC 50/60 Hz | 200...250 V DC |
| Impulse duration | 200 ms |
| Time delay range | 0.25 s |
| Threshold tripping voltage | 0.35...0.7 Un open | 0.85 Un close |
| Supply holding power | 4.5 VA |
| Supply inrush power | 200 VA |
| Mounting mode | External mounting |
| Response time | 0.25 s |
| Accessory / separate part category | Spare part for Compact NS630b...1600 | Spare part for Compact NS1600b...3200 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 8.5 cm |
| Package 1 Width | 8.0 cm |
| Package 1 Length | 9.0 cm |
| Package 1 Weight | 147.0 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 36 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 5.73 kg |
