Schneider Electric 172PNN21022
The 172PNN21022 from Schneider Electric is a Modbus Plus Adapter Module designed for precise connectivity and control. This device operates on a supply voltage of 5 Volts DC and incorporates a 9-pin D-shell connector for users.
This Schneider Electric 172PNN21022 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26805547730.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Momentum automation platform |
| Product or component type | Modbus Plus option adaptor |
| Number of port | 1 |
| Communication port protocol | Modbus Plus |
| Communication port type | Single |
| [Us] rated supply voltage | 5 V DC |
| Input voltage tolerance | +/- 5 % |
| Supply | Via I/O base |
| Clock drift | +/- 13 s/day accuracy |
| Battery type | Lithium battery - autonomy: < 30 day after the battery low indication at 40 °C |
| Battery size | 2/3 AA |
| Battery life | 5 year(s) |
| Electrical connection | 1 connector D-shell with 9 pins for Modbus Plus connection |
| Material | Lexan |
| Marking | CE |
| Local signalling | 1 LED for communication |
| Current consumption | <= 350 mA at 24 V DC | 200 mA at 24 V DC |
| Height | 25 mm |
| Width | 143.1 mm |
| Depth | 60.06 mm |
| Module format | Standard |
| Net weight | 85.05 g |
| Dielectric strength | 500 V DC |
| Standards | IEC 529 |
| Product certifications | UL | CSA | NEMA 250 type 1 |
| IP degree of protection | IP20 conforming to IEC 529 |
| Protective treatment | TC |
| Shock resistance | +/- 15 gn 11 ms half sine wave acceleration |
| Vibration resistance | 1 gn (f = 57…150 Hz) |
| Amplitude of sinusoidal vibration | 0.075 mm 10…57 Hz |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80...1000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 5…95 % without condensation |
| Operating altitude | <= 2000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 7.0 cm |
| Package 1 Width | 11.0 cm |
| Package 1 Length | 21.0 cm |
| Package 1 Weight | 211.0 g |
