Schneider Electric 170ADM39030
The Schneider Electric 170ADM39030 is a versatile component in the Modicon series, offering a total of 10 digital input channels. Through its robust design, it can operate within an input voltage range of 11 to 30 V DC, managing positive logic input control.
This Schneider Electric 170ADM39030 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Mixed io range and is referenced internally as PartLogic SKU PL26917785799.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Momentum automation platform |
| Product or component type | Discrete relay I/O base DC |
| Group of channels | 1 group of 10 inputs | 2 groups of 4 outputs |
| Discrete input number | 10 |
| Discrete input logic | Positive |
| Discrete output number | 8 |
| Network frequency | 47...63 Hz |
| Input resistance | 4 kOhm |
| Mechanical durability | 30000000 cycles |
| Protection type | Without protection |
| Isolation between channels and bus | 500 V AC |
| Terminals description PLC n°1 | (1L+)PW_POS | (3)IN_DIS#3 | (9)IN_DIS#9 | (1)IN_DIS#1 | (8)IN_DIS#8 | (6)IN_DIS#6 | (2)IN_DIS#2 | (7)IN_DIS#7 | (4)IN_DIS#4 | (L+)PW_POS | (10)IN_DIS#10 | (5)IN_DIS#5 | (M-)PW_NEG | TB |
| Terminals description PLC n°2 | (6)OUT_DIS#6 | (2L1)PW | (2)OUT_DIS#2 | TB_1 | (8)OUT_DIS#8 | (7)OUT_DIS#7 | (1L+)PW | (4)OUT_DIS#4 | (5)OUT_DIS#5 | (1)OUT_DIS#1 | (3)OUT_DIS#3 |
| Height | 141.5 mm |
| Width | 125 mm |
| Depth | 47.5 mm |
| Net weight | 0.26 kg |
| Protective treatment | TC |
| Marking | CE |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 9.000 cm |
| Package 1 Width | 18.000 cm |
| Package 1 Length | 26.000 cm |
| Package 1 Weight | 510.000 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 3.792 kg |
