Schneider Electric 170ADI54050
The 170ADI54050 discrete input base from Schneider Electric is engineered to accommodate varied input configurations effectively. This unit features 16 channels organized into two groups, each consisting of eight inputs, and is designed for use with discrete input voltages of 120V AC.
This Schneider Electric 170ADI54050 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital input range and is referenced internally as PartLogic SKU PL26907650873.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Momentum automation platform |
| Product or component type | Discrete inputs base AC |
| Group of channels | 2 groups of 8 inputs |
| Discrete input number | 16 |
| Discrete input logic | Positive |
| Voltage range | 0...132 V |
| Isolation between group | 1780 V AC |
| Isolation between channels and bus | 1780 V AC |
| Terminals description PLC n°1 | (N)PW | (5)IN_DIS#5 | (13)IN_DIS#13 | (15)IN_DIS#15 | (12)IN_DIS#12 | (10)IN_DIS#10 | (14)IN_DIS#14 | (11)IN_DIS#11 | (9)IN_DIS#9 | (7)IN_DIS#7 | (L1)PW | (1)IN_DIS#1 | (8)IN_DIS#8 | (2)IN_DIS#2 | (6)IN_DIS#6 | (16)IN_DIS#16 | (3)IN_DIS#3 | TB | (4)IN_DIS#4 |
| Local signalling | 16 LEDs for channel status |
| Height | 141.5 mm |
| Width | 125 mm |
| Depth | 47.5 mm |
| Net weight | 0.284 kg |
| Protective treatment | TC |
| Marking | CE |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 9.000 cm |
| Package 1 Width | 18.000 cm |
| Package 1 Length | 26.000 cm |
| Package 1 Weight | 501.000 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 3.006 kg |
