Schneider Electric 140NOC77101
The Schneider Electric 140NOC77101 is an Ethernet communication module designed for efficient network connectivity. It supports both EtherNet,IP and Modbus TCP protocols, accommodating up to 128 simultaneous connections.
This Schneider Electric 140NOC77101 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Communication modules > Ethernet range and is referenced internally as PartLogic SKU PL26926225980.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Ethernet communication module |
| Product compatibility | All Unity CPU |
| Communication port protocol | EtherNet/IP | Modbus TCP |
| Exchange mode | Full duplex |
| Maximum number of connections | 128 |
| Transmission rate | 10/100 Mbit/s |
| Redundancy | No standalone |
| Web server | Transparent ready class B30 |
| Communication service | DHCP/BootP server | Quality of Service (QoS) | CIP implicit messaging (I/O communication) | SOAP XML Web (client/server) | SNMP agent | FDR server | Modbus TCP messaging | CIP Explicit messaging (server and client messaging) |
| Web services | Data Editor (via PC terminal) | Rack viewer |
| Transmission support medium | Twisted pair |
| Port Ethernet | RJ45: 10BASE-T/100BASE-TX |
| Marking | CE |
| Supply | Via the power supply of the rack |
| Local signalling | 1 LED (green) for communication on the bus (Active) | 1 LED (green) for configuration status (Ready) | 1 LED (green) for connection speed (100MB) | 1 LED (green) for Ethernet network status (link) | 1 LED (green/red) for module status (Mod Status) | 1 LED (green/red) for network communication status (Net Status) | 1 LED (green) for full-duplex mode (Fduplex) | 1 LED (green) for transmission activity |
| Current consumption | 400 mA at 5 V DC |
| Module format | Standard |
| Net weight | 0.345 kg |
| Standards | EN 55011 | EN 61131-2 | UL 508 | CSA C22.2 No 142 | FM 3611 Class 1 Division 2 | IEEE 802.3 |
| Product certifications | Merchant Navy | ODVA |
| IP degree of protection | IP20 |
| Ambient air temperature for operation | 0…60 °C |
| Relative humidity | 10…95 % at 60 °C without condensation |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.0 cm |
| Package 1 Width | 16.5 cm |
| Package 1 Length | 31.5 cm |
| Package 1 Weight | 448.0 g |
