Schneider Electric 140EHC20200
The 140EHC20200 from Schneider Electric is designed specifically as a high-speed counter module within the Modicon Quantum series. It features dual counter channels capable of operating in quadrature or incremental mode, allowing diverse application uses.
This Schneider Electric 140EHC20200 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > High speed counter range and is referenced internally as PartLogic SKU PL26801467266.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | High-speed counter module |
| Number of channels | 2 |
| Addressing requirement | 6 output words | 6 input words |
| Data format | 2147483647 dec 32 bits | 65535 dec 16 bits |
| Counting input type | Incremental or quadrature |
| Counting frequency | 500000 Hz |
| Discrete input voltage | < 30 V |
| Operating mode | Incremental or quadrature discrete input |
| Input resistance | 10 kOhm discrete input |
| Operating threshold | 0...11 V single ended mode 24 V DC at state off | 0...2 V single ended mode 5 V DC at state on | 0 V single ended mode 12 V DC at state on | 13...24 V single ended mode 24 V DC at state on | 2...7 V single ended mode 12 V DC at state off | >= 1.8 V differential mode | 3.5...5 V single ended mode 5 V DC at state off |
| Discrete output number | 4 |
| Discrete output type | Field Effect Transistor (FET) |
| Discrete output voltage | 0 V switch off DC | 0.4 V switch on DC |
| Load current | 0.5 A |
| Maximum leakage current | 0.4 mA state off |
| Maximum voltage drop | <0.4 V state on |
| Protection type | 36 V transorb for discrete output |
| Isolation between channels and bus | 1780 Vrms for 60 s |
| Fault type | Loss of output field power |
| Output short-circuit protection | Blown fuse 2.5 A |
| Power dissipation | 4 + (0.4 x total module load current) |
| Bus current requirement | 650 mA |
| External power requirement | 19.2...30 V |
| Rack type | Local | Remote | Distributed |
| Local signalling | 2 LEDs for channel status |
| Marking | CE |
| Current consumption | <= 1050 mA at 24 V DC external power supply |
| Module format | Standard |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…1000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Standards | UL 508 |
| Product certifications | C-Tick.1 | CSA No 142 | FM Class 1 Division 2 | UL |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.0 cm |
| Package 1 Width | 17.0 cm |
| Package 1 Length | 32.0 cm |
| Package 1 Weight | 444.0 g |
