Schneider Electric 140EHC10500
The Schneider Electric 140EHC10500 is a high-speed counter module designed for precision in automation systems. With five channels, it features eight inputs and corresponding outputs, making it suitable for various applications requiring fast processing.
This Schneider Electric 140EHC10500 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > High speed counter range and is referenced internally as PartLogic SKU PL26805594376.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | High-speed counter module |
| Number of channels | 5 |
| Number of inputs | 8 |
| Addressing requirement | 12 output words | 12 input words |
| Data format | 2147483647 dec 32 bits | 65535 dec 16 bits |
| Counting input voltage | 30 V DC max |
| Counting input current | 7 mA |
| Counting input type | Discrete incremental counter |
| Counting frequency | 100000 Hz |
| Duty cycle | 1/1 counter input |
| Discrete input current | 5 mA |
| Operating threshold | 15...30 V single ended mode 24 V REF DC at state on | 3...5 V single ended mode 24 V REF DC at state off |
| Discrete output number | 8 |
| Discrete output type | Field Effect Transistor (FET) |
| Discrete output voltage | 0 V switch off DC | 20...30 V switch on DC |
| Load current | 0.21 A |
| Maximum leakage current | 0.1 mA state off |
| Maximum voltage drop | <1.25 V state on |
| Isolation between channels and bus | 500 Vrms for 60 s |
| Fault type | Loss of output field power |
| Output short-circuit protection | Internal |
| Power dissipation | >= 6 W |
| Bus current requirement | 250 mA |
| External power requirement | 19.2...30 V |
| Rack type | Local | Distributed | Remote |
| Local signalling | 5 LEDs for channel status |
| Marking | CE |
| Current consumption | <= 1140 mA at 24 V DC external power supply |
| Module format | Standard |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…1000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Standards | UL 508 |
| Product certifications | RINA | UL | GOST | LR | CSA Class 1 Division 2 | RRS | ABS | GL | DNV | C-Tick |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.6 cm |
| Package 1 Width | 16.0 cm |
| Package 1 Length | 31.0 cm |
| Package 1 Weight | 520.0 g |
