Schneider Electric 140DRC83000
The Schneider Electric 140DRC83000, part of the Modicon Quantum series, is configured as a relay output module featuring eight discrete channels. This unit operates efficiently with output voltage capabilities of 20 to 250V AC, as well as 30 to 150V DC and 5 to 30V DC.
This Schneider Electric 140DRC83000 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Relay output range and is referenced internally as PartLogic SKU PL26805565646.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Relay discrete output module |
| Discrete output number | 8 |
| Contacts type and composition | 1 NO/NC |
| Contact form | Form C |
| Discrete output voltage | 20...250 V AC | 30...150 V DC | 5...30 V DC |
| Addressing requirement | 0.5 output word |
| Maximum load current | 100 mA 30...50 V DC L/R = 10 ms | 2 A 250/30 V AC/DC tungsten 1/4 hp cos phi = 0.4 | 3 A 250/30 V AC/DC | 300 mA 30...50 V DC resistive | 5 A 250/30 V AC/DC resistive at 60 °C |
| Surge current | 20 A for 10 ms capacitive |
| Switching frequency | 30 Hz resistive load | F = 0.5/I²L inductive load |
| Switching capacity in VA | 1250 VA resistive |
| Maximum response time on input open | 10 ms at state 0 to state 1 | 20 ms at state 1 to state 0 |
| Mechanical durability | 10000000 cycles |
| Electrical durability | 100000 cycles 100 mA 30...150 V DC L/R = 10 ms | 100000 cycles 30...150 V DC interposing relay | 100000 cycles 300 mA 30...150 V DC resistive | 100000 cycles 5 A 30 V DC resistive | 200000 cycles 5 A 250 V AC resistive | 50000 cycles 500 mA 30...150 V DC resistive |
| Output overvoltage protection | Internal by varistor, 275 V |
| Isolation between channels | 1780 Vrms AC for 1 minute | 2500 V DC |
| Isolation between channels and bus | 1780 Vrms AC for 1 minute | 2500 V DC for 1 minute |
| Power dissipation | 2.75 W + (0.5 x the number of points on) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault detected (F) | 8 LEDs (green) for input status |
| Bus current requirement | 560 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
| Product certifications | C-Tick | GOST | GL | RMRS | FM Class 1 Division 2 | ABS | DNV | RINA |
| Standards | UL 508 | CSA C22.2 No 142 |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 16.3 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 31.2 cm |
| Package 1 Weight | 475.0 g |
