Schneider Electric 140DDO84300
Schneider Electric's 140DDO84300 is a discrete output module from the Modicon Quantum series designed for complex control applications. With 16 channels available, this module operates effectively with a discrete output voltage range between 10 and 60 volts DC.
This Schneider Electric 140DDO84300 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26805673941.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Dc discrete output module |
| Discrete output number | 16 |
| Group of channels | 2 groups of 8 |
| Discrete output logic | Positive logic (source) |
| Addressing requirement | 1 output word |
| Discrete output voltage | 10...60 V DC |
| Output voltage limits | 10.2...72 V |
| Absolute maximum output | 72 V permanent |
| Maximum voltage drop | <1 V 2 A |
| Maximum load current | 12 A per module | 6 A per group |
| Surge current | 7.5 A for 50 s |
| Response time | <= 1 ms at state 0 to state 1 | <= 1 ms at state 1 to state 0 |
| Maximum leakage current | 1 mA 60 V |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) |
| Associated fuse rating | 2 A each point | 8 A per group |
| Isolation between channels and bus | 2500 Vrms DC for 1 minute |
| Isolation between group | 700 Vrms DC for 1 minute |
| Protection type | Internal output protection by 8 A fuse per group |
| Power dissipation | 1 W + (1 V x total module load current) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault detected (F) | 16 LEDs (green) for input status |
| Bus current requirement | 160 mA |
| Module format | Standard |
| Net weight | 0.45 kg |
| Product certifications | GOST | RMRS | FM Class 1 Division 2 | C-Tick |
| Standards | CSA C22.2 No 142 | UL 508 |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.73 cm |
| Package 1 Width | 16.33 cm |
| Package 1 Length | 30.91 cm |
| Package 1 Weight | 452.6 g |
