Schneider Electric 140DDO35300
The Schneider Electric 140DDO35300 is a discrete output module from the Modicon Quantum series. It features 32 channels designed to operate at an output voltage of 24 volts DC, with limits ranging from 19.2 to 30 volts DC, and can handle a maximum load current of 4 amperes per group, totaling 16 amperes for the entire module.
This Schneider Electric 140DDO35300 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26805656644.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Dc discrete output module |
| Discrete output number | 32 |
| Group of channels | 4 groups of 8 |
| Discrete output logic | Positive logic (source) |
| Addressing requirement | 2 output words |
| Discrete output voltage | 24 V DC |
| Output voltage limits | 19.2...30 V |
| Absolute maximum output | 56 V for 1.3 s decaying pulse |
| Maximum voltage drop | <0.4 V 0.5 A |
| Maximum load current | 16 A per module | 4 A per group |
| Surge current | 5 A for 0.0005 s |
| Response time | <= 1 ms at state 0 to state 1 | <= 1 ms at state 1 to state 0 |
| Maximum leakage current | 0.4 mA 30 V |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 50 Hz |
| Fault indication | Blown fuse | Loss of field power |
| Associated fuse rating | 3 A each point | 5 A per group |
| Isolation between channels and bus | 1780 Vrms DC for 1 minute |
| Isolation between group | 500 Vrms DC for 1 minute |
| Protection type | Internal output protection by 5 A fuse per group |
| Power dissipation | 1.75 W + (0.4 V x total module load current) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault detected (F) | 32 LEDs (green) for input status |
| Bus current requirement | 330 mA |
| Module format | Standard |
| Net weight | 0.45 kg |
| Product certifications | GOST | BV | RMRS | ABS | DNV | GL | RINA | C-Tick | FM Class 1 Division 2 | safety certification non interfering |
| Standards | UL 508 | CSA C22.2 No 142 |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.59 cm |
| Package 1 Width | 16.44 cm |
| Package 1 Length | 31.09 cm |
| Package 1 Weight | 434.9 g |
