Schneider Electric 140DDI84100C
The 140DDI84100C discrete input module, part of Schneider Electric's Modicon Quantum series, features 16 discrete inputs organized into 8 channels. It has input voltage limits ranging from 10 to 60 volts with an absolute maximum of 75 volts, ensuring versatility in various applications.
This Schneider Electric 140DDI84100C is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital input range and is referenced internally as PartLogic SKU PL26902255293.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Dc discrete input modules |
| Discrete input number | 16 |
| Group of channels | 8 |
| Logic input | Positive (sink) |
| Input voltage limits | 10...60 V |
| Input voltage | 12 V 5…10 mA DC | 24 V 6…30 mA DC | 48 V 2…15 mA DC | 60 V 1…5 mA DC |
| Voltage state 1 guaranteed | 11...24 V 24 V +/- 20 % | 34...48 V 48 V +/- 20 % | 45...60 V 60 V +/- 20 % | 9...12 V 12 V +/- 5 % |
| Voltage state 0 guaranteed | 0...1.8 V 12 V +/- 5 % | 0...10 V 48 V +/- 20 % | 0...5 V 24 V +/- 20 % | 0...9 V 60 V +/- 20 % |
| Absolute maximum voltage | 75 V |
| Addressing requirement | 1 input word |
| Response time | 4 ms from state 0 to state 1 | 4 ms from state 1 to state 0 |
| Switching frequency | <= 100 Hz |
| Isolation between group and bus | 2500 Vrms DC for 1 minute |
| Isolation between group | 700 Vrms DC for 1 minute |
| Power dissipation | 1 W + (0.62 x number of points on) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault detected (F) | 16 LEDs (green) for input status |
| Bus current requirement | 200 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
| Protective treatment | Conformal coating Humiseal 1A33 |
| Standards | CSA C22.2 No 142 | UL 508 |
| Product certifications | FM Class 1 Division 2 | C-Tick |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 16.3 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 31.2 cm |
| Package 1 Weight | 468.0 g |
