Schneider Electric 140DDI36400
The Schneider Electric 140DDI36400 is a discrete input module designed to handle low-voltage DC applications. This unit supports up to 96 digital channels, operating within a voltage range of 19.2 V to 30 V DC, ensuring versatile integration into control systems.
This Schneider Electric 140DDI36400 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital input range and is referenced internally as PartLogic SKU PL26895784077.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Low voltage dc discrete input modules |
| Discrete input number | 96 |
| Group of channels | 6 |
| Logic input | Positive (sink) |
| Discrete input voltage | 24 V DC |
| Input voltage limits | 19.2...30 V |
| Voltage state 1 guaranteed | 15...30 V DC |
| Voltage state 0 guaranteed | 5 V DC |
| Current state 1 guaranteed | >= 2.5 mA |
| Current state 0 guaranteed | >= 0.7 mA |
| Addressing requirement | 6 words |
| Input impedance | 6700 Ohm |
| Absolute maximum input | 30 V continuous | 50 V decaying pulse |
| Response time | <= 2 ms from state 0 to state 1 | <= 3 ms from state 1 to state 0 |
| Power dissipation | 1.35 W + (0.13 x number of points on) |
| Isolation between group | 500 Vrms for 1 minute |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault detected (F) | 96 LEDs (green) for input status |
| Marking | CE |
| Bus current requirement | 270 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
| Standards | CSA C22.2 No 142 | UL 508 |
| Product certifications | FM Class 1 Division 2 | C-Tick |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 16.3 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 31.2 cm |
| Package 1 Weight | 520.0 g |
