Schneider Electric 140DAO85300
The 140DAO85300 discrete output module by Schneider Electric is designed for use in the Modicon Quantum series. It features 32 channels capable of operating within a voltage range of 20 to 253V AC, ensuring versatility in various applications.
This Schneider Electric 140DAO85300 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26805428213.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Schneider Electric |
| Product Line | Modicon Quantum |
| Part Number | 140DAO85300 |
| EAN | 3595860001511 |
| Weight | 2.00 lbs (0.91 kg) |
| Output Type | Discrete Outputs |
| Number of Channels | 32 Channels |
| Discrete Output Voltage | 20 to 253V AC |
| Addressing Requirement | 2 Output Words |
| Supply Frequency | 47-63 Hz |
| Maximum Voltage Drop | 1.5V |
| Groups of Channels | 4 |
| DV/dt Rating | 400V/rms |
| Absolute Maximum Output | 300Vrms at 10 s AC, 400Vrms at 1 Cycle AC |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Mounting Type | Rack Mountable |
| Surge Current | 2.5 Amps for 1 ms |
| Module Type | Discrete Output Module |
| CE Marking | Yes |
| Brand | Schneider Electric |
