Schneider Electric 140DAO84210
The 140DAO84210 from Schneider Electric is part of the Modicon Quantum series, characterized by its 16 discrete output channels. This module operates at a voltage ranging from 85 to 253 volts AC and requires a single output word for addressing.
This Schneider Electric 140DAO84210 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26805565438.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | AC discrete output modules |
| Discrete output number | 16 |
| Group of channels | 4 groups of 4 channels |
| Supply frequency | 47...63 Hz |
| maximum voltage drop | 1.5 V |
| Discrete output voltage | 83...253 V AC |
| Addressing requirement | 1 output word |
| Absolute maximum output | 300 Vrms for 10 s AC | 400 Vrms 1 cycle AC |
| Maximum load current | 2 mA rms 115 Vrms off state leakage per output | 2.5 mA rms 230 Vrms off state leakage per output | 3 A rms 170...253 V per output | 4 A rms 85...132 V per output | 16 A rms per module | 4 A rms per group |
| Surge current | 10 A during 3 cycles per point | 20 A during 2 cycles per point | 30 A during 1 cycle per point | 25 A during 3 cycles per group | 30 A during 2 cycles per group | 45 A during 1 cycle per group |
| DV/dt | 400 V/ms |
| Response time | <= 0.5 ms at state 0 to state 1 | <= 0.5 ms at state 1 to state 0 |
| Fault indication | Blown fuse | Loss of field power |
| Protection type | Internal by RC filter | Internal output protection by 5 A fuse |
| Power dissipation | 1.85 + (1.1 V x total module load current) |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault detected (F) | 16 LEDs (green) for input status |
| Bus current requirement | 350 mA |
| Module format | Standard |
| Net weight | 0.45 kg |
| Product certifications | cUL | FM Class 1 Division 2 |
| Standards | UL 508 | CSA C22.2 No 142 |
| Electromagnetic compatibility | Electrostatic discharge immunity test - test level: 4 kV (contact discharge) conforming to IEC 801-2 | Electrostatic discharge immunity test - test level: 8 kV (air discharge) conforming to IEC 801-2 | Susceptibility to electromagnetic fields - test level: 10 V/m (80...1000 MHz) conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 16.3 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 31.2 cm |
| Package 1 Weight | 634.0 g |
