Schneider Electric 140CPU65150
The 140CPU65150 from Schneider Electric features the Unity Processor, operating at a clock frequency of 166 MHz. With 768 KB of RAM, this unit is coated for enhanced protection and designed for applications in demanding environments.
This Schneider Electric 140CPU65150 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Programmable logic controllers range and is referenced internally as PartLogic SKU PL26805537678.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Unity processor |
| Clock frequency | 166 MHz |
| Number of slots | 10 | 16 | 6 | 4 | 2 |
| Number of racks | 2 - local rack(s) |
| Number of distributed I/O station | 63 station(s) - 1 rack(s) - 3 Modbus Plus network(s) |
| Number of remote I/O station | 31 - 2 rack(s) per S908 remote I/O | 31 - 2 rack(s) per ethernet Quantum remote I/O | 16 - 2 rack(s) per ethernet X80 remote I/O |
| Discrete I/O number | 31744 inputs, 31744 outputs - remote | 8000 inputs, 8000 outputs - distributed - per network Modbus Plus | Unlimited (26 slots max) - local | Unlimited (31 drops of 28 slots max) - ethernet remote I/O |
| Analogue I/O number | 500 inputs, 500 outputs - distributed - per network Modbus Plus | 1984 inputs,1984 outputs - S908 remote I/O | Unlimited (26 slots max) - local | Unlimited (31 drops of 28 slots max) - ethernet remote I/O |
| Application specific I/O | Accurate time stamping | Serial link | High-speed interrupt inputs | Counter |
| Communication service | Ethernet router |
| Number of optional modules | 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum number of connections | 1 USB | 2 AS-Interface - distributed | 4 AS-Interface - remote | 6 Ethernet TCP/IP - local | 6 Modbus Plus - local | 6 Profibus DP - local | 1 Modbus (RS232/485 Modbus/ASCII) |
| Integrated connection type | 1 Modbus Plus with | 1 Ethernet TCP/IP with | 1 Modbus with | 1 USB with |
| Checks | Process control |
| Memory description | Expandable 7168 kB - program with PCMCIA card | Expandable 8 MB - file storage with PCMCIA card | Internal RAM 768 kB |
| Switch function | Key switch memory port on/off |
| Application structure | 1 cyclic/periodic master task - | 1 periodic fast task - | 128 I/O interrupt tasks - | 128 interrupt tasks - | 32 timer interrupt tasks - | 4 auxiliary tasks - |
| Number of instructions per ms | 10.28 Kinst/ms 100 % Boolean | 10.07 Kinst/ms 65 % Boolean and 35 % numerical |
| System overhead | 0.2 ms for fast task | 1 ms for master task |
| Bus current requirement | 2160 mA |
| Local signalling | 1 LED (green) for Ethernet activity (COM) | 1 LED (red) for Ethernet collision |
| Electrical connection | 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network | 1 connector, connector type: RJ45 for connecting Ethernet network | 1 connector, connector type: RJ45 for connecting Modbus bus |
| Product certifications | Misc (Marine) | UL | CE | CSA | GOST |
| Standards | HazLoc |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 11.0 cm |
| Package 1 Width | 18.5 cm |
| Package 1 Length | 32.5 cm |
| Package 1 Weight | 1.434 kg |
