Schneider Electric 140CPU11303
The 140CPU11303 is a versatile processor belonging to Schneider Electric's Modicon Quantum series. This unit operates effectively within a temperature range of 0 to 60 degrees Celsius and supports different Modbus configurations, including 2 Modbus RS232 and 1 Modbus Plus channel. Its efficient design is complemented by a clock frequency of 20 MHz and 368 kB of internal RAM.
This Schneider Electric 140CPU11303 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Programmable logic controllers range and is referenced internally as PartLogic SKU PL26911071455.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Processor |
| Software name | ProWORX 32 | Concept |
| Processor name | 80186 |
| Mathematical coprocessor | Without |
| Clock frequency | 20 MHz |
| Memory description | Internal RAM 368 kB |
| Exact time for 1 Kinstruction | 0.3...1.4 ms LL984 |
| Watchdog timer | 250 ms |
| Clock drift | +/-8 s/day at 0…60 °C |
| I/O words | 30 I/32 O distributed | 64 I/64 O max local | 64 I/64 O remote |
| I/O words/network | 500 I/500 O distributed |
| Drops/network | 63 distributed |
| Number of drops | 31 remote |
| Number of network | 2 remote | 3 distributed |
| Battery type | Lithium 7 µA 210 µA |
| Battery capacity | 1.2 Ah |
| Battery life | 10 year(s) |
| Number of port | 1 Modbus RS232 | 1 Modbus Plus |
| Communication module processor capacity | 2 NOM, NOE, CR, NMS |
| Switch function | Without key switch |
| Marking | CE |
| Bus current requirement | 790 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
| Product certifications | FM Class 1 Division 2 | cUL |
| Standards | UL 508 | CSA C22.2 No 142 |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5 cm |
| Package 1 Width | 16.5 cm |
| Package 1 Length | 31 cm |
| Package 1 Weight | 514 g |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 7 |
| Package 2 Height | 30 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 4.113 kg |
| Unit Type of Package 3 | S04 |
| Number of Units in Package 3 | 21 |
| Package 3 Height | 30 cm |
| Package 3 Width | 40 cm |
| Package 3 Length | 60 cm |
| Package 3 Weight | 11.827 kg |
