Schneider Electric 140CPS22400
The 140CPS22400 is a power supply module in the Modicon Quantum series by Schneider Electric. This module is designed to operate with an input voltage of 24 V DC, accepting a range from 20 to 30 volts. It features an internal overvoltage protective mechanism and supports an input current of 3800 mA, ensuring efficient operation.
This Schneider Electric 140CPS22400 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Power supplies range and is referenced internally as PartLogic SKU PL26805606528.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Power supply module |
| Power supply type | Redundant |
| Input voltage | 24 V (20...30 V) DC |
| Input current | 3800 mA |
| Inrush current | 14 A 20 V | 25 A 24 V |
| Maximum input power interruption | 100 ms | 1 ms 20 V |
| Associated fuse rating | 5 A, slow-blow |
| Output voltage | 5.1 V DC |
| Power supply output current | 8 A redundant |
| Output overvoltage protection | Internal |
| Output overload protection | 2.3 x maximum rated input voltage for 1.3 ms |
| Power dissipation | 6 + (1.8 x Iout) where Iout is in A |
| Alarm output | 1 NC 6 A 220 V power supply fault |
| Local signalling | 1 LED (green) for power (PWR OK) |
| Marking | CE |
| Module format | Standard |
| Net weight | 0.65 kg |
| Standards | UL 508 | CSA C22.2 No 142 |
| Product certifications | FM Class 1 Division 2 | cUL |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 16.3 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 31.2 cm |
| Package 1 Weight | 840.0 g |
