Schneider Electric 140CPS11420C
The Schneider Electric 140CPS11420C is a modular power supply designed for the Modicon Quantum series. Operating at input voltages of 115 or 230 VAC, this unit outputs a DC voltage of 5.1 V and supports a maximum output current of 11 A.
This Schneider Electric 140CPS11420C is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Power supplies range and is referenced internally as PartLogic SKU PL26805540854.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Power supply module |
| Power supply type | Summable or standalone |
| Input voltage | 115 V (93...132 V) AC 47…63 Hz | 230 V (170...276 V) AC |
| Input current | 1300 mA at 115 V | 750 mA at 230 V |
| Inrush current | 19 A 230 V | 38 A 115 V |
| rated power in VA | 130 VA |
| Associated fuse rating | 2 A, slow-blow |
| Harmonic distortion | <= 10 % of fundamental rms value |
| Output voltage | 5.1 V DC |
| Power supply output current | 11 A 60 °C standalone | 20 A 60 °C summable |
| Output overvoltage protection | Internal |
| Output overload protection | Internal |
| Power dissipation | 6 + (1.5 x Iout) where Iout is in A |
| Alarm output | 1 NC 6 A 220 V power supply fault |
| Local signalling | 1 LED (green) for power (PWR OK) |
| Marking | CE |
| Module format | Standard |
| Net weight | 0.65 kg |
| Protective treatment | Conformal coating Humiseal 1A33 |
| Standards | CSA C22.2 No 142 | UL 508 |
| Product certifications | cUL |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 16.3 cm |
| Package 1 Width | 4.5 cm |
| Package 1 Length | 31.2 cm |
| Package 1 Weight | 834.0 g |
