Schneider Electric 140AII33000
The Schneider Electric 140AII33000 is a temperature input module designed to manage thermal measurements effectively. Equipped with eight analog inputs, it allows for diverse thermocouple configurations, offering measurement currents of either 0.5 mA or 2.5 mA.
This Schneider Electric 140AII33000 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input range and is referenced internally as PartLogic SKU PL26902231456.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Intrinsically safe temperature input module |
| Software designation | Concept version V2.2 and above | Unity Pro |
| Type of filter | Plus notch input filter 50/60 Hz thermocouple | Single low pass input filter 20 Hz thermocouple |
| Product destination | In conjunction with products for zone 20, 21 or 22 |
| Analogue input number | 8 |
| Analogue input type | Low level voltage: -100...100 mV | Low level voltage: -25...25 mV | Thermocouple: - 210...760 °C for thermocouple J | Thermocouple: - 270...1000 °C for thermocouple E | Thermocouple: - 270...1370 °C for thermocouple K | Thermocouple: - 270...400 °C for thermocouple T | Thermocouple: - 50...1665 °C for thermocouple R | Thermocouple: - 50...1665 °C for thermocouple S | Temperature probe: - 200...850 °C for Pt 100, Pt 200, Pt 500, Pt 1000 | Temperature probe: - 60...180 °C for Ni 100, Ni 200, Ni 500, Ni 1000 | Thermocouple: - 130...1820 ° C for thermocouple B |
| Measurement current | 0.5 mA Pt 500, Pt 1000, Ni 500, Ni 1000 | 2.5 mA Pt 100, Pt 200, Ni 100, Ni 200 |
| Source resistance | < 200 Ohm thermocouple |
| Input impedance | > 10 MOhm RTD | thermocouple |
| Common mode rejection | > 100 dB 50/60 Hz RTD | > 120 dB 50/60 Hz thermocouple |
| Cold junction compensation | Internal 0…60 °C thermocouple |
| Linearity | 0.003 % of full scale RTD |
| Resolution | 0.76 µV (16 bits) -25...25 mV millivolt | 3.05 µV (16 bits) -100...100 mV millivolt | 1 °C, 0.1 °C, 1 °F, 0.1 °F thermocouple | 12 bits + sign (0.1 °C) RTD |
| Measurement accuracy | +/- 2 °C + 0.1 % of reading thermocouple E | +/- 2 °C + 0.1 % of reading thermocouple J | +/- 2 °C + 0.1 % of reading thermocouple K | +/- 2 °C + 0.1 % of reading thermocouple T | +/- 4 °C + 0.1 % of reading thermocouple B | +/- 4 °C + 0.1 % of reading thermocouple R | +/- 4 °C + 0.1 % of reading thermocouple S | +/- 0.5 °C RTD at 25 °C | +/- 0.9 °C RTD at 0…60 °C | 20 µV + 0.1 % of reading millivolt at 25 °C |
| Absolute accuracy error | +/- 0.05 % of full scale RTD at 25 °C | +/- 0.1 % of full scale maximum RTD at 25 °C |
| Accuracy drift according to temperature | 0.15 mV/°C + 0.0015 % of reading/°C max thermocouple |
| Update time | 1 s TC/millivolt thermocouple | 1.35 s 3 wires RTD | 750 ms 2 or 4 wires RTD |
| Isolation between channels and bus | 1780 V 47...63 Hz AC for 1 minute | 2500 V DC for 1 minute |
| Fault type | Broken wire | Out of range |
| Power dissipation in W | 2 W |
| Hot swapping fallback | Not allowed per intrinsic safety standards |
| Protection type | Internal fuse |
| Marking | CE | II1 G/D-EEx ia IIC |
| Bus current requirement | 400 mA |
| Module format | Standard |
| Net weight | 0.3 kg |
| Standards | EN 50281-1-1 | EN 50014 | EN 50284 | CSA C22.2 No 142 | EN 50020 | Directive ATEX 94/9/EC | EN 50039 |
| Dust zone | Outside zone |
| Product certifications | hazardous location class 1, division 1 groups A, B, C | C-Tick.1 | FM Class 1 Division 2 | SIRA 02ATEX2345X |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 | 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 Hz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.5 cm |
| Package 1 Width | 16.5 cm |
| Package 1 Length | 31.5 cm |
| Package 1 Weight | 0.676 kg |
