Schneider Electric 140ACO13000
The 140ACO13000 from Schneider Electric is an 8-channel analog output module designed for the Modicon Quantum series. This unit operates within a temperature range of 0°C to +60°C and features extensive isolation capabilities for enhanced safety.
This Schneider Electric 140ACO13000 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog output range and is referenced internally as PartLogic SKU PL26801467220.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Range of product | Modicon Quantum automation platform |
| Product or component type | Analogue output module |
| Analogue output number | 8 |
| Addressing requirement | 8 output words |
| Loop voltage | 6…30 V DC |
| Maximum voltage drop | <30 V 25 mA |
| Analogue output range | 0...20 mA 0...20000 counts | 0...25 mA 0...25000 counts | 4...20 mA 0...16000 counts | 4...20 mA 0...4095 counts |
| Absolute accuracy error | +/- 0.2 % of full scale at 25 °C |
| Linearity | +/- 12 µA 4...20 mA 0...4095 counts | +/- 4 µA 0...20 mA 0...20000 counts | +/- 4 µA 0...25 mA 0...25000 counts | +/- 4 µA 4...20 mA 0...16000 counts |
| Accuracy drift according to temperature | 0.004 % of full scale/°C typical | 0.007 % of full scale/°C maximum |
| Isolation between channels and bus | 1780 V for 1 minute AC |
| Update time | 5 ms |
| Setting time | 3.2 ms to +/-0.1% of the final value | 1.6 ms to 5% of the final value |
| Fault type | Open circuit 4...20 mA |
| Bus current requirement | 550 mA |
| Maximum power dissipation in W | 5 W |
| External power requirement | 6...30 V |
| Marking | CE |
| Local signalling | 1 LED (green) for bus communication is present (Active) | 1 LED (red) for external fault | 8 LEDs (green) for channel is turned on | 8 LEDs (red) for channel fault |
| Module format | Standard |
| Net weight | 0.3 kg |
| Product certifications | cUL | FM Class 1 Division 2 |
| Standards | UL 508 | CSA C22.2 No 142 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 4.800 cm |
| Package 1 Width | 16.700 cm |
| Package 1 Length | 31.500 cm |
| Package 1 Weight | 438.000 g |
