Panasonic TQ4-5V
4PDT signal relay, 5VDC coil, 1A, through hole, 89Ohm coil.
This Panasonic TQ4-5V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805333430.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | DIP |
| Coil Current | 56.2 mA |
| Coil Power | 280 mW |
| Coil Resistance | 89 Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 5 V |
| Contact Current Rating | 1 A |
| Contact Material | Gold, Silver |
| Contact Resistance | 50 mΩ |
| Depth | 9 mm |
| Height | 5 mm |
| Insertion Loss (dB) | 0.6 dB |
| Insulation Resistance | 1 GΩ |
| Lead Free | Lead Free |
| Length | 26.7 mm |
| Max Current Rating | 1 A |
| Max Operating Temperature | 70 °C |
| Max Voltage Rating (AC) | 125 V |
| Max Voltage Rating (DC) | 110 V |
| Min Operating Temperature | -40 °C |
| Mount | PCB, Through Hole |
| Number of Pins | 14 |
| Number of Poles | 4 |
| Operate Time | 3 ms |
| Packaging | Bulk |
| Power Consumption | 280 mW |
| Power Rating | 280 mW |
| Radiation Hardening | No |
| REACH SVHC | No |
| Relay Type | Telecom |
| Release Time | 3 ms |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | 4PDT |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 110 V |
| Width | 26.7 mm |
