Panasonic TQ2SA-24V
24VDC signal relay, DPDT, 2A, surface mount, 2.88kOhm coil.
This Panasonic TQ2SA-24V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805296695.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Ambient Temperature Range High | 85 °C |
| Approvals | CSA, UL |
| Coil Current | 8.3 mA |
| Coil Power | 200 mW |
| Coil Resistance | 2.88 kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 24 V |
| Contact Current Rating | 2 A |
| Contact Material | Silver |
| Contact Plating | Gold, Silver |
| Contact Resistance | 75 mΩ |
| Current Rating | 2 A |
| Depth | 11.5 mm |
| Height | 5.9 mm |
| Insertion Loss (dB) | 0.8 dB |
| Lead Free | Lead Free |
| Length | 14 mm |
| Max Current Rating | 2 A |
| Max Operating Temperature | 85 °C |
| Max Voltage Rating (AC) | 125 V |
| Max Voltage Rating (DC) | 220 V |
| Min Operating Temperature | -40 °C |
| Mount | PCB, Surface Mount |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Operate Time | 4 ms |
| Pitch | 2.54 mm |
| Power Consumption | 200 mW |
| Radiation Hardening | No |
| Ratings | IP67 |
| REACH SVHC | No |
| Relay Type | Telecom |
| Release Time | 4 ms |
| RoHS | Compliant |
| Switching Current | 2 A |
| Switching Voltage | 220 V |
| Termination | Gull Wing |
| Test Voltage | 1.5 kV |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 220 V |
| Weight | 2 g |
| Width | 9 mm |
