Panasonic TQ2-L2-6V
Panasonic TQ2-L2-6V signal relay, DPDT, 6V.
This Panasonic TQ2-L2-6V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805326805.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | DIP |
| Coil Current | 33.3 mA |
| Coil Power | 200 mW |
| Coil Type | Latching, Dual Coil |
| Coil Voltage (DC) | 6 V |
| Contact Current Rating | 1 A |
| Contact Material | Gold, Silver |
| Contact Resistance | 50 Ω |
| Depth | 9 mm |
| Insertion Loss (dB) | 0.6 dB |
| Lead Free | Lead Free |
| Length | 14 mm |
| Max Current Rating | 1 A |
| Max Operating Temperature | 70 °C |
| Max Voltage Rating (AC) | 125 V |
| Max Voltage Rating (DC) | 110 V |
| Min Operating Temperature | -40 °C |
| Mount | Through Hole |
| Number of Pins | 10 |
| Operate Time | 3 ms |
| Power Consumption | 200 mW |
| Relay Type | Telecom |
| Release Time | 3 ms |
| RoHS | Compliant |
| Schedule B | 8536490050, 8536490050|8536490050|8536490050|8536490050|8536490050 |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125 V |
| Weight | 1.5 g |
