Panasonic TQ2-3V
Panasonic TQ2-3V signal relay, DPDT, 3VDC coil, 1A contacts.
This Panasonic TQ2-3V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805429197.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | DIP |
| Coil Current | 46.7 mA |
| Coil Power | 140 mW |
| Coil Resistance | 64.3 Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 3 V |
| Contact Current Rating | 1 A |
| Contact Material | Gold, Silver |
| Contact Plating | Gold, Silver |
| Contact Resistance | 50 Ω |
| Current Rating | 1 A |
| Depth | 9 mm |
| Height | 5.4 mm |
| Insertion Loss (dB) | 0.6 dB |
| Lead Free | Lead Free |
| Length | 14 mm |
| Max Current Rating | 1 A |
| Max Operating Temperature | 70 °C |
| Max Voltage Rating (AC) | 125 V |
| Max Voltage Rating (DC) | 110 V |
| Min Operating Temperature | -40 °C |
| Mount | Through Hole |
| Number of Contacts | 2 |
| Number of Pins | 8 |
| Operate Time | 3 ms |
| Packaging | Bulk |
| Power Consumption | 140 mW |
| Power Dissipation | 140 W |
| Radiation Hardening | No |
| REACH SVHC | No |
| Relay Type | Telecom |
| Release Time | 3 ms |
| RoHS | Compliant |
| Switching Current | 1 A |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Type | Electromechanical |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 110 V |
| Weight | 1.5 g |
| Width | 9 mm |
