Panasonic TQ2-12V
Panasonic TQ2-12V signal relay, 12VDC coil, DPDT, 1A, through hole, low profile, gold contacts.
This Panasonic TQ2-12V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805333378.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CSA, UL |
| Case/Package | DIP |
| Coil Current | 11.7 mA |
| Coil Power | 140 mW |
| Coil Resistance | 1.028 kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12 V |
| Contact Current Rating | 1 A |
| Contact Material | Silver |
| Contact Plating | Copper, Silver, Tin |
| Contact Resistance | 50 mΩ |
| Current Rating | 1 A |
| Depth | 9 mm |
| Height | 5 mm |
| Insertion Loss (dB) | 0.6 dB |
| Lead Free | Lead Free |
| Length | 14 mm |
| Max Current Rating | 1 A |
| Max Operating Temperature | 70 °C |
| Max Voltage Rating (AC) | 125 V |
| Max Voltage Rating (DC) | 110 V |
| Min Operating Temperature | -40 °C |
| Mount | PCB, Through Hole |
| Number of Pins | 8 |
| Operate Time | 3 ms |
| Power Consumption | 140 mW |
| Power Rating | 140 mW |
| Radiation Hardening | No |
| Ratings | IP67 |
| Relay Type | Telecom |
| Release Time | 3 ms |
| RoHS | Compliant |
| Switching Current | 1 A |
| Switching Voltage | 125 V |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 110 V |
| Weight | 1.5 g |
