Panasonic SF4D-DC12V
Panasonic SF4D-DC12V safety relay, 12VDC coil, 4PST-NO,NC, 6A, through hole.
This Panasonic SF4D-DC12V is supplied brand new by PartLogic for machine guarding, safety circuits, operator protection, production equipment and industrial compliance applications. It forms part of our Industrial automation > Safety > Safety light curtains range and is referenced internally as PartLogic SKU PL26801414533.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Ambient Temperature Range High | 70 °C |
| Coil Current | 41.7 mA |
| Coil Power | 500 mW |
| Coil Resistance | 288 Ω |
| Coil Type | Latching |
| Coil Voltage (DC) | 12 V |
| Contact Current Rating | 6 A |
| Contact Material | Gold, Silver, Tin |
| Contact Plating | Gold |
| Contact Resistance | 30 mΩ |
| Current Rating | 6 A |
| Depth | 33 mm |
| Height | 17 mm |
| Lead Free | Lead Free |
| Length | 53.3 mm |
| Max Current Rating | 6 A |
| Max Operating Temperature | 70 °C |
| Max Voltage Rating (AC) | 440 V |
| Max Voltage Rating (DC) | 30 V |
| Min Operating Temperature | -40 °C |
| Mount | Through Hole |
| Number of Contacts | 8 |
| Number of Pins | 18 |
| Number of Poles | 4 |
| Operate Time | 30 ms |
| Packaging | Bulk |
| Pitch | 2.54 mm |
| Power Consumption | 500 mW |
| Radiation Hardening | No |
| Ratings | IP67 |
| REACH SVHC | Unknown |
| Relay Type | Safety |
| Release Time | 7 ms |
| RoHS | Compliant |
| Switching Current | 6 A |
| Termination | PC Pin |
| Throw Configuration | 3PST, 4PST, 8PST, SPST |
| Voltage Rating (AC) | 440 V |
| Voltage Rating (DC) | 30 V |
| Weight | 47 g |
| Width | 33 mm |
