Panasonic NF4EB-12V
4PDT signal relay, 12VDC coil, 2A, through hole, 330Ohm coil.
This Panasonic NF4EB-12V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805298158.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Ambient Temperature Range High | 65 °C |
| Coil Current | 36.36 mA |
| Coil Power | 440 mW |
| Coil Resistance | 330 Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12 V |
| Contact Current Rating | 2 A |
| Contact Material | Silver |
| Contact Resistance | 50 mΩ |
| Depth | 24.6 mm |
| Height | 11.4 mm |
| Insulation Resistance | 1 GΩ |
| Lead Free | Lead Free |
| Length | 30.2 mm |
| Max Current Rating | 2 A |
| Max Operating Temperature | 65 °C |
| Max Voltage Rating (AC) | 220 V |
| Max Voltage Rating (DC) | 220 V |
| Min Operating Temperature | -40 °C |
| Mount | PCB, Through Hole |
| Number of Contacts | 4 |
| Number of Pins | 15 |
| Number of Poles | 4 |
| Operate Time | 15 ms |
| Power Consumption | 440 mW |
| Power Rating | 440 mW |
| Ratings | IP67 |
| REACH SVHC | No |
| Relay Type | General Purpose |
| Release Time | 10 ms |
| RoHS | Compliant |
| Switching Current | 2 A |
| Termination | PC Pin |
| Throw Configuration | 4PDT |
| Voltage Rating (AC) | 220 V |
| Weight | 15.5 g |
| Width | 24.6 mm |
