Panasonic MSDA021A1A
Panasonic MSDA021A1A AC servo drives provide precision control in numerous applications. It operates at 50–60 Hz with a full load current (FLC) of 6.0 amps at 100–115 volts AC in a single-phase arrangement. 80V three-phase output FLC is 2.5 amps. The drive's output frequency range is 0–333.3 Hz, providing speed control. Its 200-watt output assures motor efficiency. Position sensing is precise with a 2500 P,R encoder resolution. The MSDA021A1A drive controls motion via AC servo control.
This Panasonic MSDA021A1A is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Servo drives > Minas a4 range and is referenced internally as PartLogic SKU PL26805438335.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Mitsubishi |
| Product Type | AC Servo Driver |
| Product Line | A Series |
| Part Number | MSDA021A1A |
| Weight | 3.00 lbs (1.36 kg) |
| Input Voltage | 100-115V AC (1-phase) |
| Full Load Current (FLC) | 6.0 Amps (50-60 Hz) |
| Output Voltage | 80V (3-phase) |
| Output FLC | 2.5 Amps |
| Output Frequency Range | 0-333.3 Hz |
| Power Output | 200 Watts |
| Encoder Resolution | 2500 pulses per revolution (P/r) |
| Control Type | AC Servo |
| Control Method | Closed-loop |
| Communication | Compatible with the central controller or PLC |
| Environmental Rating | IP55 |
| Ambient Temperature Range | 0 to 40°C |
| Brand | Mitsubishi |
