Panasonic MSD5A3A1XX
The Panasonic MSD5A3A1XX is an AC servo driver that supports various applications. This driver maintains performance in a temperature range from 0 to 50°C with a storage capability of -20 to 80°C and operates effectively under ambient humidity conditions of up to 90% RH without condensation.
This Panasonic MSD5A3A1XX is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Servo drives > Minas a4 range and is referenced internally as PartLogic SKU PL26805436603.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Panasonic |
| Product Line | MS Series |
| Part Number | MSD5A3A1XX |
| Weight | 0.88 lbs (0.40 kg) |
| Product Description | AC Servo Driver |
| Ambient Operational Temperature | 0 to 50°C |
| Ambient Storage Temperature | -20 to 80°C |
| Ambient Humidity | 90% RH or less (no condensation) |
| Ambient Vibrations | 4.9 m/s² (0.5G) or less, 10 to 60 Hz |
| Applicable Load Inertia | Less than 30 times the inertia of motor (400W or less) |
| Output of Applicable Motor | 50W |
| Power Source Rated Voltage | 200V AC |
| Power Source Voltage Range | 200 to 230 VAC |
| Power Source Voltage Phase | 3-phase |
| Rotary Encoder Specification | Incremental encoder |
| Encoder Pulse Count | 2500 pulses/revolution |
| Control Method | Transistor PWM (sine-wave form) |
| Regenerative | Built-in resistor |
| Brand | Panasonic |
