Panasonic DS2E-SL2-DC24V
Discontinued by manufacturer, relay, low signal, dpdt, pcb, 24VDC, 2A, through hole, dual coil latching, solder pin, 7.5mA, rohs compliant
This Panasonic DS2E-SL2-DC24V is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805322889.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CSA, UL |
| Case/Package | DIP |
| Coil Current | 7.5 mA |
| Coil Power | 180 mW |
| Coil Resistance | 3.2 kΩ |
| Coil Type | Latching, Dual Coil |
| Coil Voltage (DC) | 24 V |
| Contact Current Rating | 2 A |
| Contact Material | Silver |
| Current Rating | 2 A |
| Depth | 9.9 mm |
| Height | 9.9 mm |
| Lead Free | Lead Free |
| Length | 20 mm |
| Max Current Rating | 3 A |
| Max Operating Temperature | 70 °C |
| Max Voltage Rating (AC) | 250 V |
| Max Voltage Rating (DC) | 220 V |
| Manufacturer Package Identifier | DS2E-SL2 |
| Min Operating Temperature | -40 °C |
| Mount | PCB, Through Hole |
| Number of Pins | 10 |
| Operate Time | 10 ms |
| Packaging | Bulk |
| Power Rating | 60 W |
| Ratings | IP67 |
| REACH SVHC | No |
| Relay Type | General Purpose |
| Release Time | 5 ms |
| Rise Time | 3 ms |
| RoHS | Compliant |
| Switching Current | 2 A |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 250 V |
| Voltage Rating (DC) | 30 V |
| Weight | 4 g |
| Width | 9.9 mm |
