Panasonic DP-011
PCA9533 LED driver, 4-channel, I2C, 2.3-5.5V, TSSOP-8.
This Panasonic DP-011 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Pressure sensors > Digital pressure sensors range and is referenced internally as PartLogic SKU PL26805290067.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | TSSOP |
| Contact Plating | Gold |
| Frequency | 400 kHz |
| Height | 950 µm |
| Lead Free | Lead Free |
| Length | 3.1 mm |
| Low Level Output Current | 25 mA |
| Max Operating Temperature | 85 °C |
| Max Power Dissipation | 400 mW |
| Max Supply Current | 550 µA |
| Max Supply Voltage | 5.5 V |
| Min Operating Temperature | -40 °C |
| Min Supply Voltage | 2.3 V |
| Mount | Surface Mount |
| Nominal Supply Current | 500 µA |
| Number of Outputs | 4 |
| Number of Pins | 8 |
| Number of Segments | 4 |
| Output Current | 25 mA |
| Power Dissipation | 400 mW |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Width | 3.1 mm |
