Panasonic APF30212
Panasonic APF30212 relay, SPDT, 12VDC, 6A, through hole.
This Panasonic APF30212 is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805297042.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Coil Current | 14.2 mA |
| Coil Power | 170 mW |
| Coil Resistance | 847 Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12 V |
| Contact Current Rating | 6 A |
| Contact Material | Silver |
| Depth | 5 mm |
| Height | 15 mm |
| Lead Free | Lead Free |
| Length | 28 mm |
| Max Current Rating | 6 A |
| Max Operating Temperature | 85 °C |
| Max Voltage Rating (AC) | 250 V |
| Min Operating Temperature | -40 °C |
| Number of Pins | 5 |
| Operate Time | 8 ms |
| Power Consumption | 170 mW |
| Power Rating | 170 mW |
| Radiation Hardening | No |
| Ratings | IP67 |
| REACH SVHC | Unknown |
| Relay Type | General Purpose |
| Release Time | 4 ms |
| RoHS | Compliant |
| Schedule B | 8536490050 |
| Switching Capacity | 1.5 kW |
| Switching Current | 6 A |
| Termination | PC Pin |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 250 V |
| Weight | 5 g |
| Width | 5 mm |
