Panasonic ALFG2PF12
Panasonic LF-G series power relay, 12VDC coil, SPST-NO, 31A, through hole, PCB mount.
This Panasonic ALFG2PF12 is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805298477.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | UL |
| Case/Package | DIP |
| Coil Current | 117 mA |
| Coil Power | 1.4 W |
| Coil Resistance | 103 Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12 V |
| Contact Material | Silver, Tin |
| Contact Resistance | 100 Ω |
| Current Rating | 117 mA |
| Depth | 15.7 mm |
| Fall Time | 10 ms |
| Height | 23.3 mm |
| Lead Free | Lead Free |
| Length | 30.1 mm |
| Max Current Rating | 31 A |
| Max Operating Temperature | 60 °C |
| Max Voltage Rating (AC) | 250 V |
| Min Operating Temperature | -40 °C |
| Number of Pins | 4 |
| Number of Poles | 1 |
| Operate Time | 20 ms |
| Power Consumption | 280 mW |
| Power Rating | 1.4 W |
| Radiation Hardening | No |
| REACH SVHC | No |
| Relay Type | General Purpose |
| Release Time | 10 ms |
| Response Time | 20 ms |
| RoHS | Compliant |
| Switching Capacity | 7.75 kW |
| Switching Current | 31 A |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 250 V |
| Voltage Rating (DC) | 12 V |
| Weight | 23 g |
