Panasonic ALE15B24
Relay, SPST-NO, 24VDC, 16A.
This Panasonic ALE15B24 is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805326342.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Coil Current | 16.7 mA |
| Coil Power | 400 mW |
| Coil Resistance | 1.44 kΩ |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 24 V |
| Contact Current Rating | 16 A |
| Contact Material | Silver, Tin |
| Lead Free | Lead Free |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Mount | Through Hole |
| Operate Time | 20 ms |
| Packaging | Bulk |
| Power Consumption | 400 mW |
| REACH SVHC | No |
| Relay Type | General Purpose |
| Release Time | 20 ms |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPST |
