Panasonic AEV110122
Panasonic AEV Series Automotive Relay, SPST-NO, 10A, 12V DC (AEV110122)
This Panasonic AEV110122 is supplied brand new by PartLogic for control circuits, automation panels, signal switching, machine safety and industrial maintenance applications. It forms part of our Industrial automation > Relays > Electromechanical relays range and is referenced internally as PartLogic SKU PL26805462524.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Ambient Temperature Range High | 80 °C |
| Coil Current | 103 mA |
| Coil Power | 1.24 W |
| Coil Resistance | 116 Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 12 V |
| Contact Current Rating | 10 A |
| Current Rating | 10 A |
| Depth | 37.9 mm |
| Lead Free | Lead Free |
| Length | 66.8 mm |
| Max Current Rating | 10 A |
| Max Operating Temperature | 80 °C |
| Max Voltage Rating (DC) | 400 V |
| Min Operating Temperature | -40 °C |
| Mount | Chassis Mount, Flanges |
| Number of Contacts | 1 |
| Number of Pins | 4 |
| Operate Time | 50 ms |
| Packaging | Bulk |
| Power Consumption | 1.24 W |
| Radiation Hardening | No |
| Relay Type | Automotive |
| Release Time | 30 ms |
| RoHS | Compliant |
| Switching Current | 10 A |
| Termination | Quick Connect |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 400 V |
| Weight | 90 g |
