Omron ZC-Q2255
Omron ZC-Q2255 limit switch, roller plunger, SPDT, 10A.
This Omron ZC-Q2255 is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Switches > Basic switches range and is referenced internally as PartLogic SKU PL26801446058.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Contact Resistance | 15 mΩ |
| Current Rating | 6 A |
| Depth | 21.7 mm |
| Differential Travel | 203.2 µm |
| Electrical Life | 500 kcycles |
| Length | 69.4 mm |
| Max Operating Temperature | 80 °C |
| Max Voltage Rating (AC) | 480 V |
| Max Voltage Rating (DC) | 250 V |
| Mechanical Life | 10 Mcycles |
| Min Operating Temperature | -10 °C |
| Mount | Panel, Screw |
| Number of Positions | 2 |
| Operating Force | 11.8 N |
| Operating Position | 47.3964 mm |
| Orientation | Straight |
| Overtravel | 2.9972 mm |
| Pretravel | 1.524 mm |
| Ratings | Dust Tight, IP67, Waterproof |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Switch Function | On-Mom |
| Termination | Screw |
| Throw Configuration | SPDT, SPST |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 30 V |
