Omron VB-2111
Omron VB-2111 limit switch, dual bevel plunger, SPDT, 10A.
This Omron VB-2111 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Vibration sensors range and is referenced internally as PartLogic SKU PL27203725851.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Current Rating | 10 A |
| Depth | 58 mm |
| Differential Travel | 508 µm |
| Electrical Life | 300 kcycles |
| Housing Material | Aluminium |
| Length | 114 mm |
| Max Operating Temperature | 80 °C |
| Mechanical Life | 5 Mcycles |
| Min Operating Temperature | -10 °C |
| Mount | Chassis Mount |
| Operating Force | 14.71 N |
| Operating Position | 26.0096 mm |
| Overtravel | 3.5052 mm |
| Packaging | Bulk |
| Pretravel | 1.524 mm |
| Ratings | Dust Tight, IP67, Waterproof |
| RoHS | Compliant |
| Switch Function | On-Mom |
| Termination | Conduit |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 125 V |
| Width | 68 mm |
