Omron NSH5-SQR10B-V2
The NSH5-SQR10B-V2 from Omron is a handheld programmable terminal,controller with a clear 5.7-inch TFT LCD display. Its maximum power consumption is 10 Watts, and it is rated for a supply voltage of 24 Volts DC. Thus, it is designed for efficient operation across various applications.
This Omron NSH5-SQR10B-V2 is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Touch panels range and is referenced internally as PartLogic SKU PL26805543088.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Omron |
| Product Type | Handheld Programmable Terminal/Controller |
| Product Line | NS |
| Part Number | NSH5-SQR10B-V2 |
| Weight | 3.31 lbs (1.50 kg) |
| Power Consumption | 10 Watts (maximum) |
| Number of Dots | 320 x 240 dots |
| Power Supply Voltage Rating | 24 Volts DC |
| Display Type | 5.7 inches TFT (Thin Film Transistor) LCD |
| Battery Life Span | 5 years at 25°C |
| Humidity Tolerance | 35% to 85% in a non-condensing environment |
| Shock Resistance | 143 meter per second squared in X, Y, and Z-axes |
| Permissible Voltage Range | 20.4 to 27.6 Volts DC |
| Ambient Operating Temperature | 0 to 40°C in a non-freezing environment |
| Case Color | Black |
| Vibration Resistance | 9.8 meter per second squared in X, Y, and Z-axes |
| Protection Class | IP65 (Water and dust-resistant) |
| Emergency Stop Switch Type | Red stop switch |
| Ethernet Port | Not available |
| Brand | Omron |
