Omron EE-SX871A
Omron EE-SX871A slot sensor, 5mm, NPN.
This Omron EE-SX871A is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric sensors > Slot type range and is referenced internally as PartLogic SKU PL26801446305.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Forward Current | 35 mA |
| Height | 21 mm |
| Housing Material | Polybutylene |
| Lead Free | Lead Free |
| Length | 18 mm |
| Max Collector Current | 100 mA |
| Max Operating Temperature | 55 °C |
| Max Supply Voltage | 24 V |
| Min Operating Temperature | -25 °C |
| Min Supply Voltage | 5 V |
| Mount | Chassis Mount, Screw |
| Number of Pins | 3 |
| Operating Supply Current | 35 mA |
| Output Configuration | NPN - Open Collector |
| Output Current | 100 mA |
| Output Type | Phototransistor |
| Ratings | IP60 |
| RoHS | Compliant |
| Sensing Distance | 5 mm |
| Sensing Method | Optical |
| Wavelength | 940 nm |
| Width | 13 mm |
