Omron CQM1-OD212
Omron CQM1-OD212 is an output control module for the CQM1 series; it offers 16 transistor points and 18 screw terminals. It can switch between 50 milliamps at 4.5 VDC and 300 milliamps at 26.4 VDC. It uses a DIN rail mounting setup and screws terminal-based termination, and it complies with CE, CSA, Lloyd, NK, and UL standards. This transistor output unit is reliable and can be used in a number of industrial settings.
This Omron CQM1-OD212 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Transistor output range and is referenced internally as PartLogic SKU PL26801467288.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Omron |
| Product Type | Transistor Output Unit |
| Product Line | CQM1 |
| Part Number | CQM1-OD212 |
| Weight | 0.38 lbs (0.17 kg) |
| Output Points | 16 |
| Maximum Switching Capacity | 50 mA at 4.5 VDC to 300 mA at 26.4 VDC |
| Leakage Current | 0.1 mA maximum |
| Residual Voltage | 0.8 V maximum |
| ON Delay | 0.1 ms maximum |
| OFF Delay | 0.4 ms maximum |
| Current Consumption | 170 mA maximum at 5 VDC |
| Fuse | 5amp fuse (one per common) |
| Mounting Type | DIN Rail |
| Termination Style | Screw Terminal |
| Approval Agency | CE, CSA, Lloyd, NK, UL |
| Brand | Omron |
