NMB 3610KL-05W-B50
NMB 3610KL-05W-B50-D00 DC Axial Fan, 92x92x25mm, 24V, 54.7 CFM, 41 dBA, Ball Bearing
This NMB 3610KL-05W-B50 is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial fans range and is referenced internally as PartLogic SKU PL26805678165.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 54.7 CFM |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 160 mA |
| Depth | 92 mm |
| Housing Material | Plastic |
| Lead Free | Lead Free |
| Length | 92 mm |
| Life (Hours) | 70000 hours |
| Max Operating Temperature | 70 °C |
| Max Power Dissipation | 3.84 W |
| Min Operating Temperature | 14 °C |
| Power Rating | 3.84 W |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| RPM | 3200 RPM |
| Schedule B | 8414599080 |
| Termination | Lead Wire |
| Voltage Rating | 24 V |
| Voltage Rating (DC) | 24 V |
| Weight | 94.800805 g |
| Width | 92 mm |
