NMB 1608VL-05W-B59
40x40x20mm DC axial fan, ball bearing, 24V, 1.68W, 10.2CFM airflow, 31.4dBA noise, rib mount, sensor, 3-wire.
This NMB 1608VL-05W-B59 is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial fans range and is referenced internally as PartLogic SKU PL26805678382.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 10.2 CFM |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 70 mA |
| Height | 40.1 mm |
| Lead Free | Lead Free |
| Length | 40.1 mm |
| Life (Hours) | 40000 hours |
| Max Operating Temperature | 158 °C |
| Max Power Dissipation | 1.68 W |
| Min Operating Temperature | 14 °C |
| RoHS | Compliant |
| RPM | 8500 RPM |
| Schedule B | 8414599080 |
| Termination | 3 Wire Leads |
| Weight | 39.916129 g |
