NMB 1608VL-05W-B40
NMB 1608VL-05W-B40-B00 DC Axial Fan, 40x40x20mm, 24V, 8.8 CFM, 29 dBA, Ball Bearing
This NMB 1608VL-05W-B40 is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial fans range and is referenced internally as PartLogic SKU PL26805658181.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 8.8 CFM |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 50 mA |
| Depth | 40 mm |
| Height | 20 mm |
| Housing Material | Plastic |
| Length | 40 mm |
| Life (Hours) | 40000 hours |
| Max Operating Temperature | 158 °C |
| Max Power Dissipation | 1.2 W |
| Min Operating Temperature | 14 °C |
| Power Rating | 1.2 W |
| Radiation Hardening | No |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| RPM | 7500 RPM |
| Schedule B | 8414599080, 8414599080|8414599080|8414599080|8414599080|8414599080 |
| Termination | 2 Wire Leads |
| Voltage Rating | 24 V |
| Weight | 39.916129 g |
