MURR 85004
XTRA-GUARD High-Flex Cable, 4×20 AWG
This MURR 85004 is supplied brand new by PartLogic for machine wiring, control cabinet connections, industrial communication, automation systems and maintenance applications. It forms part of our Industrial automation > Cabling > Connectors and cables range and is referenced internally as PartLogic SKU PL26805597219.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CE, CSA, UL, VDE |
| Case/Package | 100 |
| Color | Black |
| Conductor Material | Copper |
| Insulation Diameter | 7.5438 mm |
| Insulation Material | PVC |
| Insulation Thickness | 889 µm |
| Length | 304.8 m |
| Max Operating Temperature | 90 °C |
| Min Operating Temperature | -40 °C |
| Mount | Cable |
| Number of Conductors | 4 |
| Outside Diameter | 7.29 mm |
| RoHS | Compliant |
| Voltage | 600 V |
| Voltage Rating | 600 V |
| Voltage Rating (DC) | 600 V |
| Weight | 27.215542 kg |
| Wire/Cable Gauge | 20 AWG |
| Wire/Cable Type | Multi-Conductor |
