Mitsubishi GT2308-VTBA
The GT2308-VTBA from Mitsubishi's GOT2000 series features an 8.4-inch TFT color LCD screen with VGA resolution. This unit supports 65,536 colors and includes a user memory comprising 9 MB of ROM and 9 MB of operational RAM.
This Mitsubishi GT2308-VTBA is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Touch panels range and is referenced internally as PartLogic SKU PL26805681129.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Mitsubishi |
| Product Line | GOT2000 |
| Part Number | GT2308-VTBA |
| Weight | 3.25 lbs (1.47 kg) |
| Display Device | TFT Color LCD |
| Screen Size | 8.4 inches |
| Resolution | 640 x 480 pixels (VGA) |
| Display Colors | 65,536 colors |
| User Memory | 9 MB ROM for storage; 9 MB RAM for operation |
| Touch Panel Type | Analog resistive film |
| Backlight | Non-replaceable LED with 50,000 hours lifespan at 25°C and 50% brightness |
| Interfaces | RS-232, RS-422/485, Ethernet (100BASE-TX/10BASE-T), USB Host (1 channel), USB Device (1 channel), SD Memory Card slot |
| Power Supply Voltage | 100 to 240 V AC |
| Power Consumption | 11 W maximum |
| Protective Structure | Front: IP67F; Rear: IP2X |
| Operating Temperature Range | 0°C to +40°C |
| Panel Cut Dimensions | 227 mm x 176 mm |
| External Dimensions | 241 mm x 194 mm x 56 mm |
| Brand | Mitsubishi |
